GSM/GPS Communication module

PATRIOT EU communication module is based on the latest technologies. It is designed to protects the vehicle and transmit information to the user via the mobile application. It can work either autonomously or be connected to the car alarm. The Module is equipped with a 3D acceleration sensor which detects not only unauthorized movement and the vehicle tilt but also the vehicle accident. Thanks to small dimensions (68 x 70 x 23 mm) and integrated GPS and GSM antennas the installation is very easy and quick. Integrated back-up battery ensures the functionality also after the main power supply disconnection.


Download the application

Choose the operating system of your mobile phone

Functions


COMMUNICATION VIA MOBILE APPLICATION
A complete communication with the vehicle (alarm information transmission, localization, output control, …) is done via the mobile application.


VEHICLE TILT
This function detects tilting the vehicle. You appreciate it eg. in case of wheel theft.


ALERT FROM CAR ALARM
A communication module can be connected with the original car alarm and transmit the alarm information to the user.


CAR EMERGENCY
In case of the car accident the module will transfer an alarm with the actual position.


UNAUTHORIZED MOVEMENT
The module triggers an alarm in case of the vehicle movement with the ignition off (eg. the vehicle tow away).


CAR BATTERY VOLTAGE DROP OR DISCONNECTION
The module will inform the user in case the vehicle battery is disconnected or voltage drop (eg. unauthorized car electricity manipulation).


VEHICLE LOCALIZATION
PATRIOT EU enables the user to find out the actual vehicle position.


OUTPUT CONTROL
Can be used for the remote engine lock, parking heating etc. control.


GEOZONE
By means of the mobile application it is possible to define the geozone and receive the alert when entering or leaving it.


SPEED LIMIT
The user can define the speed limit by means of the mobile phone. In case of exceeding the speed limit an alert will be sent to the user.


VEHICLE INSPECTION
Notifies the user about the date of periodic motor vehicle inspection.


VIRTUAL GARAGE
With the function On the user gets alert when the car ignition turns On.


Hardware

PATRIOT EU communication module is based on the latest technologies. It is designed to protects the vehicle and transmit information to the user via the mobile application throughout the European Union. It can work either autonomously or be connected to the car alarm. The Module is equipped with a 3D acceleration sensor which detects not only unauthorized movement and the vehicle tilt but also the vehicle accident. Thanks to small dimensions and integrated GPS and GSM antennas the installation is very easy and quick. Integrated back-up battery ensures the functionality also after the main power supply disconnection. PATRIOT EU user features include vehicle localization, output remote control, speed limit, geofence alert (entering/leaving zone).

  • Small dimensions (68 x 70 x23 mm)
  • Integrated GPS/GSM antennas
  • 3D acceleration sensor
  • Back-up battery
  • Integrated OEM car alarm detection

Technical specification



GSM Modul SARA-G3 Quadband 850 / 900 / 1800 / 1900 MHz
Komunikace Push notification
GPS 72 channels receiver, GPS/QZSS L1 GLONASS L10F, BeiDou B1l, Galileo E1B/C, SBAS: WAAS, EGNOS, MSA, GAGAN sensitivity up to -167 dBm
3G acceleration sensor 3-axis gravity sensor
Output 1 output open collector (500mA)
Power supply 12 - 24 DC
Consumption Sleep mode < 4mA; Max. 500mA
Time synchronisation Date and time are synchronised with GPS
Dimensions 68 x 70 x 23 mm
Weight 110 g
Operating temperature -20°C to +60°C
